Category | Specifications | Data parameters | |
Appearance structure | Dimensions(L x D x H) | 700mm x 700mm x 1900mm | |
Weight | 400kg | ||
Length of charging cable | 5m | ||
Connectors | CCS1 || CCS2 || CHAdeMO || GBT || NACS | ||
Electrical indicators | Input Voltage | 400VAC / 480VAC (3P+N+PE) | |
Input frequency | 50/60Hz | ||
Output Voltage | 200 - 1000VDC (The constant power : 300 - 1000vDC) | ||
Output current (Air Cooled) | CCS1- 200A || CCS2 - 200A || CHAdeMO - 150A || GBT- 250A || NACS- 200A | ||
Output current (iquid cooled) | CCS2 - 500A || GBT- 8000A || GBT- 600A || GBT- 400A | ||
rated power | 40-240kW | ||
Effciency | ≥94% at nominal output power | ||
Power factor | 0.98 | ||
Communication protocol | OCPP 1.6J | ||
Functional design | Display | 7" LCD with touch screen | |
RFID system | ISO/IEC 14443A/B | ||
Access Control | RFID: ISO/IEC 14443A/B || Credit Card Reader (Optional) | ||
Communication | Ethernet - Standard || 3G/4G || Wifi | ||
Power Electronics Cooling | Air Cooled || liquid codled | ||
Work environment | Operating temperature | -30°C to 55°C | |
Working||Storage Humidity | ≤ 95% RH || ≤ 99% RH (Non-condensing) | ||
Altitude | <2000m | ||
Ingress Protection | IP54 || IK10 | ||
Safety design | Safety standard | GB/T,CCS2,CCS1,CHAdeMo,NACS | |
Safety protection | Overvoltage protecion, lightning protection, overcurrent protection,leakage protection, waterproof protection, etc | ||
Emergency Stop | Emergency Stop Button Disables Output Power | ||
