Category | Specifications | Data parameters | |
Appearance structure | Dimensions(l x d x h) | 660mm × 770mm x 1000mm | |
Weight | 120kg | ||
Length of charging cable | 3.5m | ||
Connectors | Ccs1 || ccs2 || chademo || gbt | ||
Electrical indicators | Input voltage | 400vac / 480vac (3p+n+pe) | |
Input frequency | 50/60hz | ||
Output voltage | 200 - 1000vdc | ||
Output current | Ccs1- 120a || ccs2 - 120a |i chademo - 120a || gbt- 120a | ||
Rated power | |||
Effciency | ≥94% at nominal output power | ||
Power factor | >0.98 | ||
Communication protocol | Ocpp 1.6j | ||
Functional design | Display | 7" Lcd with touch screen | |
Rfid system | Iso/iec 14443a/b | ||
Access control | Rfid: Iso/iec 14443a/b || credit card reader (optional) | ||
Communication | Ethernet - standard || 3g/4g modem (0ptional) | ||
Power electronics cooling | Air cooled | ||
Work environment | Operating temperature | -30°c to 55°c | |
Working||storage humidity | ≤ 95% rh || ≤ 99% rh (non-condensing) | ||
Altitude | <2000m | ||
Ingress protection | Ip54 || ik10 | ||
Safety design | Safety standard | Gb/t,ccs2,ccs1,chademo,nacs | |
Safety protection | Overvoltage protecion, lightning protection, overcurrent protection,leakage protection, waterproof protection, etc | ||
Emergency stop | Emergency stop button disables output power | ||
